FORGING MACHINES

SRGM-H

SHPK 50-60

FORGING MACHINES

SHPK 50-60
SHPK 50-60
SHPK 50-60
SHPK 50-60
SHPK 50-60
SHPK 50-60
TECHNICIAL SPECIFICATIONS STANDARD EQUIPMENTS OPTIONAL EQUIPMENTS TECHNICAL TABLE CATALOG VIDEO
  • Welded steel construction
  • 3 rolls are motorised
  • Hardened shafts from special steel material
  • Top roll hydraulic moveable up-down
  • Horizontal and vertical working position
  • Standard rolls
  • Guide rolls
  • Brake motor equipped for precision bending
  • Mobile control panel
PIPE/TUBE BENDING ROLLS
PROFILE BENDING ROLLS
ANGLE BENDING ROLLS
SPECIAL DELRIN ROLLS TO BEND ALUMINIUM AND STAINLESS STEEL
DIGITAL READOUT
OPTIONAL LATERAL ANGLE GUIDES
OPTIONAL STAIRWAY BENDING ATTACHMENT
NC CONTROL UNIT
MODEL
SHAFT DIAMETERS
LOWER ROLLS DIAMETER
TOP ROLL DIAMETER
HYDRAULIC POWER
WORKING SPEED
MOTOR POWER
WIDTH
LENGTH
HEIGHT
WEIGHT
  mm mm mm ton m/min kW mm mm mm kg
SHPK 50 50 162 152 8 4.5 1.5 750 1000 1600 510
SHPK 60 60 215 215 16 4.0 1.5 900 1500 1700 910
